InMode Picofy Picosecond Laser

InMode Picofy Picosecond Laser

InMode Picofy Picosecond Laser is an advanced picosecond laser system developed by InMode, engineered with multiple patented technologies to deliver exceptional precision, power and speed. Designed to support aesthetic practitioners in delivering consistent outcomes, Picofy combines innovative engineering with high-performance laser technology to enable precise treatments across a range of skin concerns.

Technology

Picofy (pico energy for depth)
Qmode (controlled toning & pigment stabilisation)

Features

Pulse Duration: Delivers ultra-short 300 picosecond (PS) pulses.
Peak Power: Reaches up to 2.0 GW of maximum peak power.
Wavelengths: Offers versatile handpieces supporting 1064 nm and 532 nm wavelengths.
Beam Profile: Uses a uniform “top-hat” beam profile for even energy distribution across the treatment area.
Core Technologies: Features patented Thermal Lens Control for consistent spot size and Power Factor Correction (PFC) for stable energy output.
Companion Technology: Often paired with QMode (a nanosecond Nd:YAG laser) for layered pigment and toning strategies.

Benefits

Indicated for the removal of benign pigmented lesions and unwanted tattoos, and the treatment of wrinkles and acne scars.
Delivers 300 ultra-short picosecond (PS) pulses at a maximum peak power of 2.0 GW, while maintaining a consistently high-quality beam profile at any pulse repetition rate.
Designed with multiple harmonized, integrated core components ensuring patient safety, while delivering highly efficacious treatments:
Ultra-short pulse with 1-10Hz repetition rate
Patented Thermal Lens Control system for consistent spot size
Uniform top-hat beam profile
Patented Power Factor Correction for stable energy output
Single chamber laser oscillation technology
Multiple versatile handpieces delivering 1064 nm and 532 nm wavelengths, and programmed settings allow for the selection of exact parameters for customizable procedures.

Focuses on delivering very fast, very precise bursts of energy designed to fragment pigment efficiently.

Picofy is commonly used to address:

Tattoo removal (black and coloured)
Dermal pigmentation
Melasma and post-inflammatory hyperpigmentation
Acne scarring
Enlarged pores
Skin revitalisation protocols

QMode offers multiple wavelengths and pulse modes, allowing tailored energy delivery based on pigment type, depth and treatment objective.

It is commonly used for:

Epidermal pigmentation (sun spots, freckles, lentigines)
Dermal pigmentation
Melasma protocols
Tattoo removal
Acne scarring

Specifications

Laser type: Picosecond Nd:YAG
Wavelengths: 1064 nm + 532 nm
Pulse duration: 300 ps
Peak power: Up to 2.0 GW
Repetition rate: 1–10 Hz
Beam profile: Uniform Top-Hat
Spot size: Zoom: 2–10 mm
Handpieces: Zoom, Array MLA 110, Peak MLA 60
